Name: Hastelloy C22 Condenser Pipes &amp; Tubes
SKU: MET5050
Price: 4300.00 INR
Availability: InStock

Hastelloy C22 Condenser Pipes & Tubes

₹4,300.00

Hastelloy C22 Condenser Pipes & Tubes Manufacturers in India. Hastelloy C22 Condenser Pipes & Tubes Suppliers, UNS N06022 Condensers Tubes, 2.4602 Condenser Pipes & Tubes

Metline Industries is a professional manufacturer, distributors and supplier of high quality Hastelloy C22 condenser tubes, with annual sales of over 2000 tons. Hastelloy C22 are high-performance qualities and resistance to corrosion and oxidation. It performs well in both low and high temperature applications where other materials such as steel and aluminum would fail, and is also resistance to pitting, corrosion cracking and crevice. Metline manufactures high temperature cooling tubes for condensers and heat exchangers to various industries.

Hastelloy C22 condenser pipes & tubes are supplied with Plain end, Bevel end, Square cut under request, and deburring. Hastelloy C22 condenser tubes are commonly manufactured with an O.D. of 5/8″, 3/4″, and 1″. Some applications, particularly ammonia chillers, use larger O.D. tubes than these. Hastelloy C22 condenser tubes can also be internally and externally enhanced to further increase their efficiency.
We are recognized as a leading supplier of Hastelloy C22 condenser and boiler tubing and pipe, meeting the needs of fabricators and producers for straight length, finned, and U-bend materials. Hastelloy C22 condenser tubes are specifically designed to efficiently condense process fluid off of the outside of the tube. We use our resources and experience to offer our customers an extensive array of alloys and products, provide the quality each customer expects at the lowest possible cost and deliver it on time. We work together with our customers to develop lower cost options.
We are a leading stockiest and supplier for the welded Hastelloy C22 condenser tubes as per ASTM, DIN and ASME standards. Metline Industries specialized in heat exchanger/condensers tubing, which are manufactured using superior grade of steel. We can offer 100% Hydrostatic Test or 100% Eddy Current Test for all the condenser tubes supplied by us. All tubes are accompanied with certifications as per EN 10204 3.1.

Production & Supply Range for Hastelloy C22 Condenser Pipes & Tubes

Item	Hastelloy C22 Condenser Pipes & Tubes
Specifcation	ASTM B619, ASTM B622, ASTM B626
Size	3/8″ OD to 3″ OD (Imperial and Metric sizes)
Thickness	1 mm- 13 mm
Length	3 MTRS, Custom Length
Test Certifcate	EN 10204 3.1

SKU: MET5050 Categories: Hastelloy, Pipe Fittings

Additional information
Reviews (0)

Additional information

About Hastelloy C22	Hastelloy C22, also known as alloy C22, is a versatile austenitic nickel-chromium-molybdenum-tungsten alloy with enhanced resistance to pitting, crevice corrosion and stress corrosion cracking. The high chromium content provides good resistance to oxidizing media while the molybdenum and tungsten content give good resistance to reducing media. Hastelloy C22, also known as alloy C22, is a versatile austenitic nickel-chromium-molybdenum-tungsten alloy with enhanced resistance to pitting, crevice corrosion and stress corrosion cracking.
What is a Condenser?	A condenser is a device or unit used to condense a substance from its gaseous to its liquid state, by cooling it. In so doing, the latent heat is given up by the substance and transferred to the surrounding environment. Condensers can be made according to numerous designs, and come in many sizes ranging from rather small (hand-held) to very large (industrial-scale units used in plant processes). For example, a refrigerator uses a condenser to get rid of heat extracted from the interior of the unit to the outside air. Condensers are used in air conditioning, industrial chemical processes such as distillation, steam power plants and other heat-exchange systems. Use of cooling water or surrounding air as the coolant is common in many condensers. o Condenser, a part of a refrigeration system, is a type of heat exchanger that transforms gas or vapor into a liquid that transfers heat from the tube to the air near the tube in a very rapid manner. Condenser work process is an exothermic process, so the condenser temperature is high.
Product	Hastelloy C22 Condenser Pipes & Tubes, UNS N06022 Condenser Tubes, 2.4602 Condenser Tubes
Equivalents	Hastelloy C22, UNS N06022, 2.4602
Size	OD: 6 mm – 219.1 mm Thk: 1 mm- 13 mm, Custom Thickness Length: Custom Lengths Available
Tensile Strength	Psi – 100000, MPa – 690
Yield Strength (0.2%Offset)	Psi – 45000, MPa – 310
Elongation	45%
Chromium	20% – 22.5%
Nickel	50.015%
Surface Finish	Annealing, Pickling and Polishing
Standard	ASTM B619, ASTM B622, ASTM B626 etc.
Types	Air cooled condensers, Water cooled condensers, Evaporative condensers
Application	Vessels manufacture, Chemical industry, Potassium industry, Sea water desalination, Refrigeration industry, Ship building, Heat recovery
Packing	Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Delivery Time	15-45 days (based on quantity) after receiving advanced payment by T/T or LC
